Dayton 1TDP9 Blower, 174 CFM, 115V, 0.60 Amp, 1650 RPM
4.6 (91 items)
Limited Time Sale$70.79 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 221092909 | Release Date | 2026/05/03 | List Price | $47.20 | Model Number | 221092909 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
OEM Blower, Outlet Shape Rectangular, With/Without Flange Without Flange, Wheel Dia. 5-3/16", Wheel Width 1-7/8", CFM @ 0.000-In. SP 174, CFM @ 0.100-In. SP 162, CFM @ 0.200-In. SP 152, CFM @ 0.300-In. SP 134, CFM @ 0.400-In. SP 118, CFM @ 0.500-In. SP 95, Voltage 115, Hz 50/60, Phase 1, Full Load Amps 0.60, RPM 1650, Bearing Type Ball, Motor Type Permanent Split Capacitor, Motor Enclosure Open, Motor Insulation Class B, Thermal Protection Auto, Lead Length 13", Conduit Box Yes, Max. Ambient Temp. 104 Degrees F, Max. Inlet Temp. 104 Degrees F, Inlet Dia. 4-3/4", Outlet Height 2-7/8", Outlet Width 3-5/16", Overall Height 7-13/16", Overall Width 6-1/2", Overall Depth 7-15/16", Wheel Type Forward Curve, Drive Type Direct, Mounting Position All Position, Housing Finish Enamel, Housing Material Rolled Steel, Housing Color Gray, Agency Compliance UL Recognized US and Canada (E47479), CE, Replaces 1C982.
- 173 cfm, 1650 rpm, .60 amps, 115 volts 60/50Hz
- Mounting - all position; not recommended for speed control
- Automatic overload protection; ball bearings
- Non reversible - blower has no power cord or switch
- One year manufacture warranty
| UPC | 190735147115 |
|---|---|
| Model | 1TDP9 |
| Speed | 1650 RPM |
| Brand Name | Dayton |
| Unit Count | 1.0 Count |
| Item Weight | 6.15 Pounds |
| Part Number | 1TDP9 |
| Manufacturer | Dayton |
| Material Type | Copper |
| Item Type Name | Blower, 174 cfm, 115V, 0.60A, 1650 rpm |
